29th Street Extension
Project Specifications
Foundation
Car parking 2’ above ground (road) level
Ground floor 3’ above ground (road) level
Flood proofing & making sure our apartment is on an elevated level
Structure
RCC framed structure with earthquake resistant design. Earthquake
proofing is our 1st priority with grade 1 steel used for the structure
top & graded concrete
Walls
Exterior wall with weather proofing & climate proof
Exterior paints – 9 inches thick
Interior wall – 4½ inches thick
Main Door
Teakwood frame & door with latch, locks and magic eye
Other Door
Painted teakwood frame with solid flush door with latch & locks
Windows
Grade 1 UPVC windows with glazed single shutters with pinhead
glass. Grade 1 UPVC sliding window for service area. Top Grade
MS grills for windows
Toilets
WPC frame with door for toilets and utility areas
Flooring
Vitrified flood tiles in living room, dining, bedrooms, balcony, service
area & kitchen with skirting (24” x 24”)
Priced at Rs 50/- per sq. ft
Toilets
Coloured ceramic floor & wall tiles up to 7’ (10”x15”) on walls
Priced at Rs 35/- per sq. ft
Kitchen
Coloured ceramic tiles up to 2’ of backsplash
Staircase
Tiles/ Marble/ Granite flooring with stainless steel railing
Electric Board – Independent 3-phase connections and EB panel
board for electricity distribution
Power – Three-phase electricity supply for each flat with a separate
meter
Power backup – Solar panels + Generator – Automatic power
backup for lift, water motors, common lighting and CCTV. Automatic
power backup for all lighting and fan points for all flats
Camera – Availability of security cameras in the common area
Security – A proper security room with attached toilet
Lift – Automatic lift with a capacity of 5 passengers
Kitchen - 2 chrome plated taps ; RO plumbing & electrical point
Dining – White/Ivory wash basin
Toilet - White/Ivory – wall-mounted water closet + health faucet +
wash basin
Electrical point for exhaust fan
Shower rose with a hot and cold water tap
Provision for water heater
NOTE: When sanitary ware other than the specified color is chosen by the
customer, the price difference shall be reimbursed by the customer
Wiring – Concealed copper wirings, sheets and modular switches
conforming to ISI specifications. Necessary electrical points shall be
provided with MCB circuit breakers
Living Room – 2 - 5 amps power points, 3 light points, 2 fan points, 1
television point & 1 telephone point.
Bedroom – 1 - 5 amps power points, 2 light points, 1 fan point & 1
split A/C point to all bedrooms.
Toilet – One 15 amps power point for water heater & 1 light point
Kitchen – 2 light point, 1 fan point, 3 - 5 amps power points, 1 - 15
amps power point, 1 fridge point & 1 exhaust fan point.
Balcony – 1 light point
Utility – 1 light point, one 15 amps points
Power – 3-Phase electrical service connection
General – Calling bell point, concealed wiring with necessary point &
phase changer. Internet and cable TV provision in all rooms
NOTE: Two 15 amps (Fridge & washing machine) provided in a place of
client’s choice
Walls & Ceiling
Two coat putty, one coat primer and two coats emulsion paint
Doors
Two coats enamel paint of standard quality over one coat of primer
to all doors, windows, and grills
Main door
Front door shall be finished with varnish accordingly
Kitchen
Stainless steel sink, storage shelves and “L” shaped loft storage in the kitchen
Kitchen countertop (10’0”x2’0”) of highly polished black or red granite
over reinforced concrete slab with ceramic tiles (2’6” from countertop)
Bedroom : Built-in wardrobe of 7’0”x3’0” and a loft of 10’0”x 2’0”
will be provided in every bedroom
Water tank – Two tanks – metro and bore water. Kitchen taps
will be connected to metro water and toilets with bore water. A
common overhead tank with common lines shall be provided
Bore well – Two bore well with a motor are provided
Sump & Metro water – Metro water service connection shall be
provided and an underground sump of capacity 15,000 litres for
storing metro water
Sewerage – A proper sewerage system shall be provided
Rainwater – Two professional rainwater harvesting systems
Terrace – A wash basin with a tap shall be provided for common use
Elevation – Apartments designed functionally and aesthetically by COA registered and LEED architects
Terrace – Traditional weathering course layer (brick + jelly + lime +kaduka + waste oil + jaggery + Kerala tiles) & waterproofing layer
Toilet – All toilets are chemically treated for waterproofing & termite
Woodwork – Any carpentry work done by the buyer will be permitted after handover
Compound – Secure compound wall with MS gates and lighted wicket gates
Car parking allotment painted yellow and black
Charging points shall be provided to charge electric vehicles*
Gas Point – Provision for cooking gas pipeline *
*These amenities are provided depending on the specifications of the individual projects
Setback area – Provision of set back area with paver blocks flooring
Board – Individual name boards for name and house number in brass
Material – All the materials used are of ISI quality.
Plan – State of the art design that envelopes principles of Vaastu shastra, designed by our in-house architects CMDA & Corporation approved plans. RERA approved projects
Any change in the specifications other than what is agreed by both
parties in the construction agreement will form the basis for an
increase or decrease in agreed rates.
• Any Masonry or architectural change will be changed accordingly.
Architectural changes should be approved by our in house
architects.
• In case of any increase in rates due to a change in technical
specifications, the same shall be paid before taking up work.
• Any decrease in cost due to a change in specifications the same
shall be adjusted in the relevant stage of the payment.
